1. The LED and LCD display windows intuitively grasp the working status of the whole machine.
2. Automatic frequency tracking, phase angle control, high output efficiency and stability. Even if the impedance changes due to changes in load such as liquid temperature, depth, type, cleaning material, and negative pressure state, even if the voltage of the power source fluctuates, stable power can be supplied.
3. Efficient and unique cooling air duct, anti-corrosion design, suitable for long-term work in humid and corrosive environment.
4. Automatic wide-band scanning, which can select different frequency bands to eliminate standing waves, improve ultrasonic energy distribution, eliminate cleaning blind spots, and have unique and unique functions such as frequency adjustment and frequency compensation.
5. The output power is adjustable, the cleaning time can be set arbitrarily, and the frequency can be adjusted to meet different product cleaning needs.
6. Adopt digital control technology, perfect circuit design and stable power output.
7. Optional frequencies 17khz, 20khz, 25KHZ, 28KHZ, 30khz, 33khz, 40KHZ
8. Ultrasonic power: 200W ~ 2400W, 2500W ~ 10000W (customized) or higher power.
9. Independently develop unique advanced ultrasonic generation technology, which can reach the global advanced level.
10. It can be designed according to customer's requirements to manufacture generators with different frequency, power and function. An external remote control system can be used to operate the process through the network.
|
Type |
Power(W) |
Frequency (KHz) |
Transducer numbers |
Size |
AC110V60HZ+/-10% USA /LATIN AMERICA STANDARD ARE AVAILABLE
AC220V50HZ+/-10% EUROPE/ASIA/OCEANIA/AFRICA ARE AVAILABLE
All of machine are available for opening remote control function to connect with your own PLC system |
|
HS-QXDY-300W |
300W |
17khz,20khz,25khz,28khz,33khz,40khz
Frequency is adjustable |
3-6 |
300x360x150 |
|
HS-QXDY-600W |
600W |
17khz,20khz,25khz,28khz,33khz,40khz
Frequency is adjustable |
6-12 |
300x360x150 |
|
HS-QXDY-900W |
900W |
17khz,20khz,25khz,28khz,33khz,40khz
Frequency is adjustable |
9-18 |
300x360x150 |
|
HS-QXDY-1000W |
1000W |
17khz,20khz,25khz,28khz,33khz,40khz
Frequency is adjustable |
10-20 |
300x360x150 |
|
HS-QXDY-1200W |
1200W |
17khz,20khz,25khz,28khz,33khz,40khz
Frequency is adjustable |
12-24 |
300x360x150 |
|
HS-QXDY-1500W |
1500W |
17khz,20khz,25khz,28khz,33khz,40khz
Frequency is adjustable |
15-30 |
300x360x150 |
|
HS-QXDY-1800W |
1800W |
17khz,20khz,25khz,28khz,33khz,40khz
Frequency is adjustable |
18-36 |
300x360x150 |
|
HS-QXDY-2000W |
2000W |
17khz,20khz,25khz,28khz,33khz,40khz
Frequency is adjustable |
20-40 |
300x360x150 |
|
HS-QXDY-2400W |
2400W |
17khz,20khz,25khz,28khz,33khz,40khz
Frequency is adjustable |
24-48 |
300x360x150 |
|
HS-QXDY-3000W |
3000W |
17khz,20khz,25khz,28khz,33khz,40khz
Frequency is adjustable |
50-60 |
300x360x150 |
|
High Frequency |
300W-1200W |
54KHZ,60KHZ,68KHZ,70KHZ,80KHZ,100KHZ,120KHZ,135KHZ |
|
High Frequency |
100W-300W |
175-200KHZ |
|
Above ultrasonic generator 110V-120V or 220V-240V are available,contact with us during your order with detail request |
