Features;
1 Thoroughly clean the dead corner of the workpiece: the ultrasonic cleaning machine can not completely and effectively clean the workpiece by hand and other cleaning methods, and has a remarkable cleaning effect, which can thoroughly meet the cleaning requirements and remove the stains at the corners of the complex workpiece.
2 kinds of workpiece batch cleaning: no matter how complicated the shape of the workpiece, put it into the cleaning liquid, as long as it can contact the liquid, ultrasonic cleaning can be achieved. Ultrasonic cleaners are especially suitable for workpieces with complex shapes and structures;
3 multi-function cleaning: ultrasonic cleaning machine can combine different solvents to achieve different effects and meet different supporting production processes, such as: degreasing, derusting, dust removal, wax removal, chip removal, removal or phosphating, passivation, pottery , plating, etc.
4 reduce pollution: ultrasonic cleaning can effectively reduce pollution, reduce the damage of toxic solvents to humans, environmentally friendly and efficient.
5Reducing labor: The ultrasonic cleaning machine can realize automatic cleaning and drying of the workpiece. It is only necessary to configure one operation staff at the workpiece cleaning and loading end, which greatly reduces the number of personnel and cleaning time required for manual cleaning.
6 Shortening the working time: Compared with manual cleaning, the ultrasonic cleaning machine is shortened to one quarter of the manual cleaning;
7 Reduce labor intensity: Manual cleaning: The cleaning environment is harsh, the manual labor is heavy, and the complicated mechanical parts need to be cleaned for a long time. Ultrasonic cleaning: low labor intensity, clean and orderly cleaning environment, and automatic and efficient cleaning of complex parts.
8Environmental protection and energy saving: Ultrasonic cleaning is equipped with a circulating filtration system, which can realize repeated use of circulating filtration of cleaning solvent, which is of great significance for saving water resources, cleaning solvent cost and improving corporate environmental image.
|
Type |
Power(W) |
Frequency (KHz) |
Transducer numbers |
Size |
AC110V60HZ+/-10% USA /LATIN AMERICA STANDARD ARE AVAILABLE
AC220V50HZ+/-10% EUROPE/ASIA/OCEANIA/AFRICA ARE AVAILABLE
All of machine are available for opening remote control function to connect with your own PLC system |
|
HS-QXDY-300W |
300W |
17khz,20khz,25khz,28khz,33khz,40khz
Frequency is adjustable |
3-6 |
300x360x150 |
|
HS-QXDY-600W |
600W |
17khz,20khz,25khz,28khz,33khz,40khz
Frequency is adjustable |
6-12 |
300x360x150 |
|
HS-QXDY-900W |
900W |
17khz,20khz,25khz,28khz,33khz,40khz
Frequency is adjustable |
9-18 |
300x360x150 |
|
HS-QXDY-1000W |
1000W |
17khz,20khz,25khz,28khz,33khz,40khz
Frequency is adjustable |
10-20 |
300x360x150 |
|
HS-QXDY-1200W |
1200W |
17khz,20khz,25khz,28khz,33khz,40khz
Frequency is adjustable |
12-24 |
300x360x150 |
|
HS-QXDY-1500W |
1500W |
17khz,20khz,25khz,28khz,33khz,40khz
Frequency is adjustable |
15-30 |
300x360x150 |
|
HS-QXDY-1800W |
1800W |
17khz,20khz,25khz,28khz,33khz,40khz
Frequency is adjustable |
18-36 |
300x360x150 |
|
HS-QXDY-2000W |
2000W |
17khz,20khz,25khz,28khz,33khz,40khz
Frequency is adjustable |
20-40 |
300x360x150 |
|
HS-QXDY-2400W |
2400W |
17khz,20khz,25khz,28khz,33khz,40khz
Frequency is adjustable |
24-48 |
300x360x150 |
|
HS-QXDY-3000W |
3000W |
17khz,20khz,25khz,28khz,33khz,40khz
Frequency is adjustable |
50-60 |
300x360x150 |
|
High Frequency |
300W-1200W |
54KHZ,60KHZ,68KHZ,70KHZ,80KHZ,100KHZ,120KHZ,135KHZ |
|
High Frequency |
100W-300W |
175-200KHZ |
|
Above ultrasonic generator 110V-120V or 220V-240V are available,contact with us during your order with detail request |
