300W-3000W Hesen Ultrasonic Cleaner Generator For Cleaning Parts

Working volt: 220V(±10%) or 110V(±10%)

Working current:Please notice that equipment can not work long time under the current which is greater than the rated current.

Ultrasonic power 300W 600W 900W 1200W 1500W 1800W 2000W 2400W 3000W

Working current 1A 2.5A 3.5A 4A 4.5A 5.5A 6.5A 8.5A 12A

Working Environment temperature: 0-40C°

Relative humidity: 40%–90%

Working frequency: 28KHz(40KHz,80 KHz,135KHz, etc)

Time control: 0—59 minutes 59 seconds

Range of power control: 0-100% digital control and adjustment of 16 grades

Internal overtemperature protection: 65 C°



Some Application of Ultrasonic Frequency Signal Generator 2000w Pzt Electric Generator for Cleaning Transducer



Ultrasonic Circuit is the main parts of ultrasonic cleaning syste,which is for cleaning Electronic workshop,industrial and mining enterprises,laboratories,hospitals,glass shop,jewelry shop,mobile phone repair shop,family and so on

Some Features of Ultrasonic Frequency Signal Generator 2000w Pzt Electric Generator for Cleaning Transducer

Timer Function:set working time from 0-60 mins according to the cleaning objects.



Sweep frequency tracking function:achieved sweep frquency cleaning and automatic frequency tracking.



Display working time.frquency.current by digital.More intuitive and convenient for data observation.



With over-voltage,over-current and overheating protection function,which prevent tube and plate from burning,reduced damage to the generator.



Effective power output which is as high as 98% above.



External PLC control switch.the remote control ultrasonic cleaning machine.



Ultrasonic power,time and frequency can be Continuous adjustable.

Type	Power(W)	Frequency (KHz)	Transducer numbers	Size
AC110V60HZ+/-10% USA /LATIN AMERICA STANDARD ARE AVAILABLE AC220V50HZ+/-10% EUROPE/ASIA/OCEANIA/AFRICA ARE AVAILABLE All of machine are available for opening remote control function to connect with your own PLC system
HS-QXDY-300W	300W	17khz,20khz,25khz,28khz,33khz,40khz Frequency is adjustable	3-6	300x360x150
HS-QXDY-600W	600W	17khz,20khz,25khz,28khz,33khz,40khz Frequency is adjustable	6-12	300x360x150
HS-QXDY-900W	900W	17khz,20khz,25khz,28khz,33khz,40khz Frequency is adjustable	9-18	300x360x150
HS-QXDY-1000W	1000W	17khz,20khz,25khz,28khz,33khz,40khz Frequency is adjustable	10-20	300x360x150
HS-QXDY-1200W	1200W	17khz,20khz,25khz,28khz,33khz,40khz Frequency is adjustable	12-24	300x360x150
HS-QXDY-1500W	1500W	17khz,20khz,25khz,28khz,33khz,40khz Frequency is adjustable	15-30	300x360x150
HS-QXDY-1800W	1800W	17khz,20khz,25khz,28khz,33khz,40khz Frequency is adjustable	18-36	300x360x150
HS-QXDY-2000W	2000W	17khz,20khz,25khz,28khz,33khz,40khz Frequency is adjustable	20-40	300x360x150
HS-QXDY-2400W	2400W	17khz,20khz,25khz,28khz,33khz,40khz Frequency is adjustable	24-48	300x360x150
HS-QXDY-3000W	3000W	17khz,20khz,25khz,28khz,33khz,40khz Frequency is adjustable	50-60	300x360x150
High Frequency	300W-1200W	54KHZ,60KHZ,68KHZ,70KHZ,80KHZ,100KHZ,120KHZ,135KHZ
High Frequency	100W-300W	175-200KHZ
Above ultrasonic generator 110V-120V or 220V-240V are available,contact with us during your order with detail request
