Ultrasound detection:
In order to achieve good performance and maintain the performance of the machine, it is very important to adjust the resonance between generator and transducer system.
A: Before tuning, make sure that the welding head and the secondary rod must be locked. When tuning, the welding head should not touch other objects.
B: Turn on the power switch and the power indicator lights up.
C: Press the ultrasonic test switch and look at the load meter. (If the ammeter pointer is over 30% or more than 2A, the time to press the ultrasonic test switch is very short.) Adjust the tuning inductance and rotate left and right until the minimum position of the load meter is indicated, usually between 5% and 15% or 300 MA-900MA.
D: Because of the clamp position, the adjusting range of the tuning inductance is only 360 degrees. If the frequency of the welding head is far different from that of 20KHZ or 15KHZ, the cover should be opened and the fixed position should be removed to adjust.
