Ultrasonic Dispersion Equipment Bubbles Removal Degassing 20KHz

Ultrasonic Dispersion Equipment Bubbles Removal Degassing 20KHz Introduction

Ultrasonic Dispersion Equipment Bubbles Removal Degassing 20KHz

biodiesel ultrasonic reactor for sale 20khz 1000Watt ultrasonic reactor biodiesel



Ultrasound cell crusher, also known as ultrasonic cell crusher, is a multi-functional and multi-purpose instrument which uses strong ultrasound to produce cavitation effect in liquid to process substances by ultrasound. It can be used to break up many kinds of animal and plant cells and virus cells. At the same time, the ultrasonic cell breaker can be used to emulsify, separate, homogenize, extract, defoam, clean and accelerate chemical reaction.

1. Technical characteristics

(1) Cavitation occurs around the vibrating rod, and the ultrasonic energy is evenly distributed around the groove or cylinder, thus achieving the best cleaning effect.
(2) The power output of the ultrasonic vibration rod is not affected by the load changes such as liquid level, tank capacity and temperature difference, and the power output is stable and uniform.
(3) Compared with the traditional ultrasonic vibration plate, the ultrasonic cell breaker has a service life of more than 1.5 times.
(4) The cylindrical design enables the cell breaker to be conveniently installed at any position in the tank.
(5) Ensure complete sealing and waterproof.


Tubular Equipment
Type
Frequency
(KHz)
Ultrasound
Output(W)
Total Length
(mm)
Diameter
(mm)
Static Capacity
(pF±10%)
HS-ZDB1000W 20 1000 500 Φ50-55 68000
HS-ZDB1500W 20 1500 850 Φ50-55 68000
HS-ZDB2000W 20 2000 1100 Φ50-55 132000




Ultrasonic Dispersion Equipment Bubbles Removal Degassing 20KHz
Ultrasonic Dispersion Equipment Bubbles Removal Degassing 20KHz
