25KHz Submersible Ultrasonic Cleaning Vibration Tubular Stick

25KHz Submersible Ultrasonic Cleaning Vibration Tubular Stick

Biodiesel ultrasonic transducer, also known as ultrasonic tubular rod, ultrasonic vibration rod is a kind of multi-functional and multi-purpose instrument which uses strong ultrasound to produce cavitation effect in liquid to process substances by ultrasound. In industrial applications, the use of ultrasonic vibration rods for cleaning, mixing, extraction, stirring, chemical reaction, scale prevention, water treatment and so on is a widely used technology.
Technical characteristics:
1. Cavitation occurs around the vibrating rod, and the ultrasonic energy is evenly distributed around the groove or cylinder to achieve cleaning effect.
2. The cylindrical design can make the cell breaker conveniently installed in any position in the tank.
3. The equipment is small, easy to install and operate.

Tubular Equipment Type	Frequency (KHz)	Ultrasound Output(W)	Total Length (mm)	Diameter (mm)	Static Capacity (pF±10%)
HS-GSZDB1000W	25-27	1000	500	Φ50-55	68000
HS-GSZDB1500W	25-27	1500	850	Φ50-55	68000
HS-GSZDB2000W	25-27	2000	1100	Φ50-55	132000
