Ultrasonic Liquid Processor Vibration Rod For Mixing/Stirring

Ultrasonic Liquid Processor Vibration Rod For Mixing/Stirring

Ultrasonic dispersion holding points are usually small in vibration and large in acceleration. Ultrasonic dispersing devices have been widely used in food, fuel, new materials, chemical products, paints and other fields.
The principle of ultrasonic cell disruption is based on the cavitation of ultrasonic waves in a liquid. The transducer generates high-intensity shear force in the liquid at the top of the tool head through the horn, forming a high-frequency alternating water pressure, so that the cavity Expansion and explosion break the cells. On the other hand, due to the violent disturbance of the ultrasonic waves propagating in the liquid, the particles generate a large acceleration, thereby colliding with each other or colliding with the walls to break.
Ultrasonic cell disruption is the conversion of electrical energy into energy through the transducer. This energy is turned into a dense small bubble through the liquid medium. These small bubbles burst rapidly and produce the same energy as a small bomb. An instrument that breaks the action of substances such as cells. The working principle of the sonic cell breaker is based on the cavitation of the ultrasonic wave in the liquid. The transducer generates high-intensity shear force in the liquid at the top of the tool head through the horn, forming a high-frequency alternating water pressure, making it empty. The cavity expands and explodes to break the cells. On the other hand, due to the violent disturbance of the ultrasonic waves propagating in the liquid, the particles generate a large acceleration, thereby colliding with each other or colliding with the walls to break.
The above effects are also sufficient to uniformly mix two (or more than two) non-phase solutions. Because the device can achieve the effects of general mechanical agitation or mashing, it is widely used in the process of crushing animal and plant tissues, viruses, bacteria and other cellular structures as well as in chemical reactions such as emulsification, separation and homogenization. In the fields of biochemistry, medical pharmacy, food testing, environmental monitoring and so on.

Tubular Equipment Type	Frequency (KHz)	Ultrasound Output(W)	Total Length (mm)	Diameter (mm)	Static Capacity (pF±10%)
HS-ZDB1000W	20	1000	500	Φ50-55	68000
HS-ZDB1500W	20	1500	850	Φ50-55	68000
HS-ZDB2000W	20	2000	1100	Φ50-55	132000
